Perhaps the ideal way to identify bees is to hand off your specimens to a trained specialist, someone fluent in the complicated vocabulary of taxonomy. However, there are nowhere near enough experts available, so most of us will have to work through keys and puzzle over tricky characters to arrive at an ID. With this resource, the aim is to at least de-mystify the terminology. Also: note that vocabulary and observation are linked: if you know half a dozen terms describing surface sculpture, you will begin to see the details that distinguish them. Then, when you write your own taxonomic resources, you will provide more precise guidance to your own audience.

This glossary covers most of what you will encounter in typical keys. The universe of all technical terms is much larger. For these consider two other resources free on the internet: The Bees of the World, by Michener is a comprehensive treatment of morphology, biology, identification of ... bees of the world. The Hymenoptera Anatomy Ontology Portal has definitions for thousands of terms, though many relate to non-bee taxa.

Author: David Cappaert, Quamash EcoResearch. Images by David Cappaert, unless otherwise credited. Thanks to Laurence Packer, and Sam Droege et al, whose photos cover many taxa beyond those I know.
Collaborators: Clare Maffei, USGS/FWS Native Bee Lab; Initial idea: Codey Mathis of Penn State. Detailed edits: Lisa Robinson, Washington Native Bee Society.
Feedback: cappaert@comcast.net.


Click any image to see larger version

Clickable Image
      Morphology Overview
A B C D E F G H I J K L M O P Q R S T U V W X Y Z

A


abdomen

For insects in general, the third, posterior body region. For bees, wasps, and ants, there is a wrinkle: the apparent abdomen is properly called the metasoma, because the first abdominal segment is actually integral to the second body region, the mesosoma, or apparent thorax. Taxonomic literature typically uses the technical term: metasoma. DiscoverLife prefers the less precise but more commonly understood term: abdomen. In either scheme, tergae are numbered as shown in the image at right.

return to top

Metasoma and numbered tergae in yellow. For abdominal segments, the count would start at the posterior of the mesosoma, in red. This specimen is female; there would be 7 visible segments in a male.

abscissa

Not a specific vein, but a description of a segment of a wing vein that is delimited by the intersection of other veins. E.g., if Main Street were a vein, one abscissa would be the stretch between 1st and 2nd.


acarinarial fan

Acarinarial fan refers to the divergent pattern of appressed hairs on the anterior face of the first tergum of some Lasioglossum. This in contrast to erect hairs that may also be present.

return to top

View of anterior face of the first abdominal tergite of Lasioglossum (dialictus).

acarinarium

A specialized anatomical structure which is evolved to facilitate the retention of mites on the body of an organism (Wikipedia). In bees, these stuctures may be internal or external, on either the abdomen or thorax.

return to top

Mites associated with acarinarium of Lasioglossum titusi.
Image from the Wikipedia page, which also discusses the host/mite relationship. In some cases, the entire anterior portion of the metasoma is hollowed out into an enormous internal chamber, entered through a small opening on the face of the first metasomal tergite, in which the mites can travel.

adventitious vein

A wing vein that is not homologized (i.e., not of common evolutionary origin) with a standard wing vein.


aedeagus

The reproductive organ of male insects. The aedeagus is specifically the intromittent part of the phallic apparatus since it contains the terminus of the genital exit tract (Snodgrass 1941). See genitalia.

return to top

Colletes, BIRL/USGS

angulate

Forming an angle rather than a curve.


antenna

A paired, segmented sensory structure receptive to smell, touch, vibration, temperature and humidity. Antennae of bees are comprised of 1) the long first segment, the scape; 2) the second segment, the pedicel; 3) the flagellar segments, 10 for females and 11 for males. Like with any other trait, there will be exceptions; Trigona carbionaria have 3 fewer segments for each sex.

return to top

The 3 parts of a bee antenna.
The exceptional antennae of a male Melissodes.
Antennae with segments indicated. Males have one more segment than females, as well as a shorter scape (1st segment).

annulate

Furnished with or composed of rings. E.g., the visible segmentation of insect larvae.


arcuate

Smoothly rounded; shaped like a bow, or arch.  E.g., the arcuate  basal vein of a halictid bee wing.

return to top


anterior

Situated near or towards the head. Overview of orientation terms here.  Possibly confusing: the legs of bees may be oriented with the anterior side facing downward. Imagine the specimen standing on its toes, as in image at right.

return to top

In this view the anterior sides of the legs are in fact facing forward. Andrena anisochlora male.

apex / apical

Towards the end of a structure. A common usage: apical hair bands differentiate Halictus from the otherwise similar Lasioglossum, that have basal hair bands. Overview of orientation terms here.


apodeme

Internal sclerite that serves as an attachment site for muscles. These may be formed from infoldings of the exoskeleton, externally visible as a pit or sulcus (groove).


appressed (hairs)

Hairs that lie flat to the integumental surface. Appressed hairs are often tomentose.

return to top

Anthophorine bee. BIRL/USGS

areolate

A type of sculpturing, forming small, enclosed, and often rounded spaces. Alveolate is similar:   honeycombed; with regular, deep, angular cavities.

return to top

Fig. 21, Areolate-Rugose, from Surface Sculpturing, Harris 1979.
Areolate surface of Agapostemon mesepisternum.
Areolate surface of Sphecodes male propodeum.

arolium

A pad between the tarsal claws, present in most, but not all species. Among the megachilidae, the absence of an arolium is diagnostic of genus Megachile.

return to top

Left: tarsal claw with arolium (Melissodes). Right: Claw lacking arolium (Megachile).

axilla

Sclerites on either side of the postero-lateral margin of the scutum. In most genera, these are functionally a portion of the scutellum, but are of scutal origin. In the parasitic genera, Coelioxys, Dioxys, and Triepeolus, the axillae are produced posteriorly as distinct spines, or teeth.

return to top

Axillary spines of Coelioxys.
Triangular axillary spines of Epeolus interruptus (DiscoverLife)

B


basal

Part of a structure nearest to its point of attachment to the body. E.g., the anterior edges of tergites. E.g., the mandibular teeth closest to the clypeus. Overview of orientation terms here.

return to top

Basal hairbands distinguish Lasioglossum from Halictus. In the magnified image, note the blue pollen grains of Gilia.
Same feature. Abdominal hairbands are clearly beneath the apical edge of the previous segment.

basal vein

Forewing vein separating the radial and medial cells.    For most taxa, the basal vein is straight (-ish) or gently curved.  For Lasioglossum, and Halictidae in general, the vein is arcuate (arched).

return to top

Left: Lasioglossum: arcuate basal vein arising from the origin at a right angle (inset). Right: Hylaeus: curved but connection is less than a right angle.

basitarsus

The first and longest of 5 segments comprising the tarsus. The final segment is the distitarsus; the segments in between are the mediotarsi.

return to top

Some Megachile males have impressive basitarsi.
Another Megachile, another interesting architecture.

BeeMachine

BeeMachine is an AI tool for identifying bees, developed by Brian Spiesman at Kansas State University. Humans, especially users of this glossary, will make IDs by carefully considering a series of known traits. An AI will make IDs based on a "gestalt" gleaned from thousands of training images. We are a long way from a robust tool that will ID most of the 20,000 bee species. But BeeMachine uses Bombus as a proof-of-concept taxon. Given a photo, it will provide a match to one of 132 species. Anyone can visit the www site to upload an image for ID.

An accurate ID of a prepared specimen
An accurate ID from a field photo.
Sep 2024: entry from the upgrade of the beemachine www site, which includes images, range maps, and brief info on many species.

bidentate

Having two teeth or two projections suggestive of teeth. Describing mandibles, "bidentate" would contrast to a one or three tooth condition. Bidentate can also be used in contrast to emarginate, a condition where the teeth are incompletely separated by a medial indentation--see examples for the labral process of Andrena..

return to top

Bidentate mandible of a male Andrena.
Bidentate labral process of Andrena.

bifid (bilobed)

Forked; divided into two parts. Bilobed is roughly synonymous.

return to top

Tarsal claw of Melissodes.
Colletes collect their cell lining material from the exserted sting with their deeply bifid glossae. Glossal Morphology of the Colletidae and Recognition of the Stenotritidae at the Family Level.

C


cardo

The sclerite that articulates basally with the head, attached distally to the stipes. The cardines (plural) extend the mouthparts forward; see this in the video (Paleontological Research Institute) To see its place in relation to other mouthparts, see tongue.

return to top


carina

Ridge, or raised line demarcating an edge.

return to top

Agapostemon virescens: propodeum enclosed by carina.
Anthodioctes calcaratus male T1 with raised carina, photo: C. Ritner, Exotic Bee ID.
The hypostomal carina of Osmia.

carinae of the propodeum

Among Lasioglossum, the carinae of the propodeum are important traits that differentiate subgenera and species.   A lateral carina wholly or partially separates the vertical posterior face of the propodeum from the sides. When present, the oblique (or posterior) carina extends medially across the dorsolateral slope of the propodeal enclosure.

return to top

An incomplete lateral carina, which does not reach the dorsolateral slope of the propodeum. Oblique carina absent.
A complete lateral carina, which reaches the dorsolateral slope. There is also an oblique carina, the portion that continues medially.
Another specimen with complete carinae, a typical feature of subgenus Sphecodogastra.

cleft

A narrow space in the surface of something; also a location in the field from which you will never recover your killing jar.


clypeus

The area of the head between below the epistomal suture and above the labrum

return to top

Modified from Michener 1994
Clypeus of Andrena rugosa. BIRL/USGS.
The atypical clypeus of the colletid Geodiscelis longiceps Packer. Photo from Laurence Packer. Lab www site.

colors

In taxonomic treatments, the color of hairs, integument, and maculations is often described with a somewhat cryptic technical vocabulary. The terms (e.g., ferrugineous) do not have precise definitions; rather, their meaning varies by taxon and taxonomist. The photo suggests roughly how some technical terms compare; see other glossary entries for specifics on each term.

A rainbow Anthophora, approximating the color range for technical terms.

Color examples, and an excuse to display a set of beautiful postal stamps featuring native bees. "Royal Mail commissioned research, which found that although 87% of respondents thought bees were important 53% could not name one type of bee." ((Design Week)

return to top

Yellow colors ochracous or flavous.
Tibial scopa pink, fulvous.
Metasoma fox-colored, rufous.
Integument black, piceous.
Metasoma ferrugineous, mesosoma testaceous.

condylar ridge

The ridge that runs from the lower basal attachment of the mandible, to the apex.


corbicula

A concave surface bounded by hairs, which functions to hold collected pollen. Most often referring to the structure on the hind tibia of apine bees; also called the "pollen basket." Corbicula can also refer to similar structures on the thorax of Andrena.

return to top

Above: pollen load on the hind tibial corbicula of a honeybee. Below: corbicula of Bombus impatiens.
Bare corbicula of Bombus. Photo from Laurence Packer. Lab www site.
Andrena laden with pollen, carried both on tibial scopae and propodeal corbiculae.

coriaceous / coriarious

Leathery. Among bees, usually in reference to surface texture. Of course the texture of leather is not one thing, but depends on the source material and tanning process. As applied to bees, "finely reticulate" might be a rough synonym.

return to top

Our best approximation of standard for coriaceous.
Coriaceous integument of Lasioglossum tergum.

costal vein

The costal cell lies on the upper edge of the forewing, proximal to the stigma - see wing. To our knowledge it is rarely significant in diagnosis.


coxa

The basal segment of the leg, it is perhaps better understood as the ventral attachment point for the articulating leg segments. The coxa is usually very difficult to see on a mounted specimen.

return to top

Anterior view of foreleg of Halictus farinosus.
A diagnostic feature from DiscoverLife key for Megachile male: stout hairs at base of forecoxal spines.

crenulate

Having a margin or contour with shallow, usually rounded notches and projections; finely notched or scalloped.

return to top

Crenulate clypeal margin of Anthidium manicatum.

crista

A ridge or crest. The definition overlaps with that for carina. A crista is usually a single feature - a series of ridges might be striate, rugose, or carinulate.

return to top

Andrena may exhibit a median crista on the labrum. This is typically obscured by hairs (left image).

cuckoo bees

Also termed kleptoparasites, cuckoo bees rob the nests of other bee species. Wikipedia: Cuckoo bees enter the nests of pollen-collecting species, and lay their eggs in cells provisioned by the host bee. When the cuckoo bee larva hatches it consumes the host larva's pollen ball, and, if the female kleptoparasite has not already done so, kills and eats the host larva. Kleptoparasitic species appear among Apidae, Halictidae, Megachilidae, and other bee families. In each case, females lack the pollen collecting structures typical of the taxon.

Cuckoo Megachilidae: Coelioxys sp.
Cuckoo Apidae: Triepeolus
Cuckoo Halictidae: Sphecodes sp.
Bombus includes typical pollen collecting species, and cuckoos. B. ashtoni above is a cuckoo. Clue: no corbicula on hind leg.
Photo from Laurence Packer. Lab www site.

cuneate

Wedge-shaped; narrowly triangular, wider at the apex and tapering toward the base.

return to top

Cuneate tibia of Andrena (apex 1.5 times broader than basitarsus); alternatives are tibia parallel-sided, or apex narrower.

D


decussate

Describes a crossing (due to the shape of the Roman numeral for ten, an uppercase 'X'). For bees, a term that describes mandibles that extend past each other.

return to top

Indisputably decussate (and bidentate): mandibles of  Protosmia rubifloris.
NOT decussate: mandibles overlap, but the tips do not pass each other to form a cross.

denticle/dentiform/dentist

A projection resembling a tooth; shaped like a tooth; tooth care practioners.

return to top

Ask your dentist for a few of these specimen cleaning tools. Charm your dentist by explaining: "I need them to comb my bees..."

depressed (area)

Where bees go when they just don't care anymore. Also, the apical (posterior) portion of a tergum, depressed relative to the anterior portion. AKA apircalimpressed area, mardinal zone.

return to top

The relative length of the T2 depressed area (bracket above) is a diagnostic character for Andrena and Lasioglossum.
In this Anthidium, the elevation change is less clear; however there is a distinct transition to the apical "depressed" area where the punctation is small and crowded.

disc

The central surface of a structure, such as the clypeus or (most commonly) tergum. For Epeolus, "discal patch" refers to the discal region of T1 that is typically covered in dark tomentum and is bordered by bands of pale tomentum. Many illustrated examples in A revision of the cleptoparasitic bee genus Epeolus for Nearctic species, north of Mexico.

Quadrangular discal patch on T1, of Epeolus olympiellus. iNaturalist observation by Aidan Hersh.
Wide discal patch on  T1, of Epeolus autmnalis. iNaturalist observation by Corey Hayes.

distal

Situated farthest from the center, median line, or point of attachment or origin. See also: orientation terms.


distitarsus

Fifth, terminal tarsal segment bearing the claws.

return to top

Distitarsus of Ptilothrix bombiformis

E


emarginate

Describing a margin, such as the edge of an eye or sclerite, where the outline includes a concave section as if a part of the region had been "cut out" or displaced. (Wikipedia).

return to top

Emarginate clypeus of Megachile.
Emarginate T6 of Megachile.

entire

An edge that is straight or convex, in contrast to shapes with indentations (crenulate, emarginate, bidentate).


episternum / episternal groove

With reference to bees, episternum generally refers to the mesepisternum. The episternal groove (when present) runs vertically on the anterior side of the mesepisternum, posterior to the omalus. The groove position varies by taxon.

return to top

Photo from Laurence Packer. Lab www site.

epistomal suture

The suture that demarcates the top of the clypeus.

return to top


F


fascia

Short appressed hairs on either the basal or apical edge of metasomal tergae. AKA hair bands.

Andrena, with T2 fascia interrupted medially, T3-T4 complete.

femur

Leg segment distal to the trochanter, proximal to the tibia.

return to top

The curiously modified (and useful) metafemora of select Ceratina males.

ferrugineus

Color terms in taxonomic works are problematic, as their meanings vary by taxon and taxonomist. One place to start, for ferrugineus, is the Grammatical Dictionary of Botanical Latin which offers: the color of iron-rust, dark-red, rusty, light brown with a little mixture of red.

Reviewing the use of this term for bees suggests that tawny or rust are close. Either of those terms is more precise than "ferrugineous." Other better, more descriptive, everyday words that could be used: copper, brick-red, burgundy, chestnut, auburn, chestnut.

return to top

One wonders how often color term precision is critical in diagnosis. Bombus exhibit a wide range of colors within species. One contibuting factor: sun exposure. The effect of photobleaching on bee (Hymenoptera: Apoidea) setae color and its implications for studying aging and behavior.

fimbria

A fancy word for fringe. A desciptor for the dense band of hairs at the apices of tergae 5 and 6 (T5, T6), the prepygidial and pygidial fimbria. The hairs on the apical edge of a tergite might also be termed fimbriae.

return to top

Fimbria apical to T5 and T6, dorsal view.  Fig. 19, Michener 1994)
Fimbria associated with the labral process of Agapostemon splendens.


flagellum / flagellomere

The flagellum is the third segment of a bee antenna, distal to the scape and pedicel. The subdivisions (typically numbering 10 for females and 11 for males) are flagellomeres, though it is common to refer to these as segments. Referenced in keys, the flagellomeres are given numbers: F1, F2 being the first and second.

return to top


flocculus

The trochanteral flocculus is an accessory pollen collecting structure of the hind trochanter of Andrena.

Long, curled hairs on trochanter--a complete flocculus.
Shorter, straighter hairs on trochanter--an incomplete flocculus.

focus-stacking

Most of the macro images in the glossary are focus-stacked. The technique is a way around the problem of very limited depth of field in highly magnified images. A camera is mounted on a rail that moves it progressively closer to the subject, in increments of as little as 15 microns (at 10X). Each forward step of the camera captures a sharp image at one distance. The set of 20-50 resulting images are then combined in software to make a final image in focus across the depth of the subject.

First image in the stack. The wing and hind leg are in focus.
Last image in the stack. Hairs of the scutum and metasoma are in focus.
Final, stacked image.

fovea / foveate

Generally, a pit or depression in a structure. Most commonly referring to the facial fovea, distinct depressions in the integument medial to the eye. In Andrena these are covered with short appressed hairs (Details for Andrena. In other andrenids, Colletes, and Hylaeus the fovea are bare.

Foveate (and dimunitive foveolate) might also mean something closer to punctate. E.g., see images in A taxonomic study of the Brazilian turtle ants (Formicidae: Myrmicinae: Cephalotes). Patterns described as foveate would be characterized as punctate by many.

Fovea of Andrena. The color, depth, and shape of fovea are important diagnostic traits.
Hairless fovea of Panurginus.
Another kind of fovea, on T2 of   Megachile rotundata.

frons

Area on the front of the head above the antennal sockets and below the ocelli.

Figure modified from Bees of the World.
Frons of Andrena walleyi, marked by "coarse longitudinal rugulae and fine shagreening." (DiscoverLife page)

fulvous

Color term described by the  Grammatical Dictionary of Botanical Latin as: tawny, 'dull yellow with a mixture of gray and brown' (Lindley), yellowish-brown (Stearn), dull yellowish-brown (S&D), lion-colored; 'deep yellow, reddish yellow, gold-colored, tawny;' (fungi) “reddish-cinnamon-brown; also tawny, reddish-yellow ; the color of lions; “tawny; dull yellow-brown” (Magill 1990).

Reviewing the use of this term for bees suggests that tawny or dull orange are close. Either of those terms is more precise than "fulvous." Other better, more descriptive, everyday words that could be used:  amber, buff, golden-brown, caramel, apricot, and of course, "color of lions."


fuscous

Color term described by the Grammatical Dictionary of Botanical Latin as: fuscous, a somber brown, "'brown tinged with greyish or blackish' (Lindley); “dusky [i.e. dark], too brown for a gray; the word is akin to furvus” (Jackson); grayish-brown (Fernald 1950); 'very dark blackish brown' (Dade), but often used to indicate darkness of color" (Stearn); classically 'dark-colored, dark, black, swarthy, dusky, tawny.

A reasonable guess is that fuscous is used comparitively. E.g., "black to fuscous pubescence" meaning that some hairs are browner than jet-black. There are probably better, more descriptive, everyday words that could be used. E.g., cocoa, walnut, chestnut, coffee, burnt sienna.

G


galea

A paired, blade-shaped appendage that, together with the glossa and labial palps, forms the channel through which bees sip nectar.

Position of the galea for a long-tongued bee.

gena

The side of the head, also called the cheek.

The width and shape of the gena are common as diagnostic traits.
Megachile pugnata is distinctive for the posteroventral "genal tooth" BIRL/USGS

genitalia

The genitalia are complex, with dozens of terms for constituent parts that differ radically in appearance for different taxa. The topic is not represented in this glossary because 1) traits of the genitalia are so difficult to see and interpret that most non-experts ignore them; 2) the non-expert author of this resource does not yet understand the topic.

Genitalia of a bee I could not identify. Mike Arduser, a true expert, named the genus from just this image.

gimmes

The path to an ID is often arduous, hinging on a particular combination of traits. Occasionally there are taxa that can be unambiguously identified with a single trait. Experienced taxonomists probably have a long list of these. I have just a few.

Andrena astragali is the only bee that you will observe on death camas, which is toxic to every other bee.

Halictus ligatus (female) has a distinct tooth on the lower cheek.

As it happens, Megachile pugnata has a similar feature that is unique in that genus.

(Photo Vermont Center for Ecostudies)
Inwardly curving (basket-like) hypostomal hairs are unique to Euthosmia, which has just two species: O. glauca, O. densa.

glabrous

Bald, hairless, smooth, without hairs or sculpture. Also described as "polished." In image at right, the reflective surfaces are glabrous.


glossa

The terminal section of the “tongue” of a bee, usually the longest structure in the middle of all other “tongue-looking” mouthparts (Identification of Bees in Southwest Idaho). The length of the glossa (and associated mouthparts) determines the range of flowers on which a bee can forage. Bees are referred to as short or long tongued; these categories are defined by the structure of the labial palps, and do not strictly correlate with the actual tongue length.

A particularly elaborate glossa of a short-tongued bee. Photo from Laurence Packer. Lab www site.
Rotated Image
Bombus consobrinus male. Image from Artsdatabanke. The page for this species includes a video of this bee foraging.
Orchid bee. Photo by João Vitor Oliveira de Souz from Encyclopedia of Life.

gradulus

A transverse line on metasomal tergae and sterna of some bees that is formed by a groove or a step between two regions that differ in height. This line can be well developed and present across the entire segment but can also be diminished or absent through part of the segment, requiring close inspection. (Exotic Bee ID)


gynandromorph

A bee (or other taxon) that is a hermaphrodite, frequently showing a bilateral division between male and female traits.

Lasioglossum hitchensi. The antenna on the left is female, with 12 segments. On the right, a 13-segmented male antenna. BIRL/USGS
Agapostemon. Half of the clypeus (the front plate of the head) is male, half female (bilaterally) similarly one mandible is male and one female. The male has 6 tergites like the female, but the coloration is mostly male, which is brownish, but, interestingly there are some spots on the abdomen that are metallic green which is female. BIRL/USGS

H


hair bands

Bands of hair across the the metasomal tergae. In relation to each tergum, these may be basal or apical.

Apical hair bands of Andrena. For various species, these may be complete, partial, or absent.
Basal hair bands of Lasioglossum.

hamuli

Hook-like setae on the anterior margin of the hind wing which interlock with the recurved posterior edge of the fore wing in the Hymenoptera during flight, making them functionally two winged (source). These are perfectly effective for bees, but fail entirely when attempting to position the wings when mounting on a pin.


head dimensions

Head dimensions--length/width--are important in many keys and species diagnoses. Width is taken as the maximum distance across the eyes. Length (height) is typically measured from the top of the head (vertex) to the bottom of the clypeus. An alternative measure of height runs from the median ocellus to the bottom of the clypeus; this has been termed "face length." Face length will of course yield a smaller number for the length/width ratio, so it is critical to know when that metric is used.

By the conventional measure of head dimensions, the ratio for this Andrena is 0.86.
Additional metrics. Modified from Fig. 10-3, Bees of the World.

hyaline

A fancy word for clear, colorless, transparent.

The hyaline wing of Colletes hyalinus. Photo from Laurence Packer. Lab www site.
Hyaline apical margins of T2 and T3, Lasioglossum hyalinum.

humeral angle

The curve of the posterior pronotal edge, akin to shoulder when viewed from in front. The term has another meaning for Lepidoptera. This is a bee glossary.

Humeral angle absent.
Humeral angle present.
Humeral angle distinct.

hypostomal (area)

The underside of the head, lateral to the hypostomal carina and behind the mandibular base, is the hypostomal area, or, according to Eickwort (1969b), the postgena (Bees of the World).

Posterior view of head,  Lasioglossum.

hypostomal carina

The ridge on the back of the head along the oral cavity that normally delimits the hypostoma from the gena and occiput. (Hymenoptera of the World).

Hypostomal carinae of Lasioglossum cressonii (left): parallel. The otherwise similar L. bruneri (right): carinae divergent and reflexed.
The height and curvature and/or modifications are traits in the DL Ceratina and Osmia keys.

I


imbricate

Overlapping in sequence, as tiles or shingles on a roof; resembling overlapping tiles, as decoration or drawings (Dictionary.com). In a google search, one finds many scutums and metasomas described as imbricate. I strongly suspect that imbricate is used as a synonym for tesselate.

Posterior face of Lasioglossum propodeum.
Imbricate particularly in upper corners. Andrena

impunctate

Without punctation (pits). This might commonly describe a contrast between a smooth area in an otherwise pitted (punctate) region.

For the second tergite of Osmia, the width of the apical impuncate band is a diagnostic trait.
Median impunctate band, Andrena clypeus.
Lasioglossum titusi is distinguished by the (relatively) impunctate vertex.

J


jugal lobe

The posterior, proximal area of the hind wing, adjacent to the vannal lobe. The size of the jugal lobe, particularly relative to the length of the vannal lobe, features in keys.

Jugal=blue; Vannal = green. Modified from Fig. 41, Morphology and External Morphology of Bees

K


keirotrichia

On the hind tibia of most bees the keirotrichia is an area of variable size covered with hairs of uniform length, usually blunt, truncate, or briefly bifid. These hairs, the keirotrichia (Fig. 10-11), appear to serve for cleaning the wings. Text and image from Bees of the World.



kleptoparasite

See cuckoo bees.


L

labial palpus

A paired sensory appendage attached basally to the prementum. In long-tongued bees, the first and second segments are elongate, and form part of the feeding channel formed with the galea and glossa. The labial palps of short-tongued bees are of 4 equal segments; don't confuse these with the maxillary palps.

Labial palps of Andrena, a short-tongued bee.
Elongate labial palp of a long-tongued bee.

labrum / labral process

sclerite found below the clypeus, either articulated there or fused to it .. often referred to as the “upper lip” based on the Latin origin of the term, it is considered an important element of insect food manipulation (Orr and Tripodi, 2017).

In reference to Andrena,  the labral process is a basal elevated plate on the labral surface.The term process is misleading because this plate does not project, as one expects of a process. In other bees, e.g., the Panurginae (see Ruz, 1986), the same structure is called the basal area of the labrum. Use of the word “process” in the sense of basal area is further confusing because in some bees, especially the Halictidae, there is an entirely different process on the apex of the labrum, here called the apical process of the labrum. (Bees of the World, P. 45).

Position of the labrum between the mandible and clypeus.
A broad articuation of the labrum is a feature of Pararophites.
Position of the labral process realtive to the labrum.

lacinia

A small lobe or  scale at the base of the galea on the anterior margin of the maxilla. In Apis the laciniae function, along with the epipharynx, to close over the basal part of the food channel so that when the proboscis is partly folded the bee can draw nectar basad, up the anterior surface of the labiomaxillary tube to the mouth, which is at the base of that surface of the labiomaxillary tube beneath the epi pharynx (Snodgrass, 1956). Excerpt and image from Michener, Charles D., and Les Greenberg. “The Fate of the Lacinia in the Halictidae and Oxaeidae (Hymenoptera-Apoidea).” Journal of the Kansas Entomological Society, vol. 58, no. 1, 1985, pp. 137–41.


lamella

A thin plate of exoskeleton, somewhat blade-like.

Basoventral lamella of an Andrena mandible.

lineolate

Longitudinally marked with very fine raised or depressed lines.


M


maculated/maculation

A discrete area of colored integument.

Nomada take maculation to an extreme.
A hat-shaped clypeal maculation differentiates male from female Ceratina.

malar space

The area between the bottom of the compound eye and the top of the mandible. Malar space is an important trait for Bombus. From Bumblebees of Montana: One of the most challenging characters used to key out bumble bees is the length of the malar space (i.e. cheek) compared to its width. The length of the cheek is measured from the lower margin of the compound eye to the attachment of the mandible. The width of the cheek is measured below the compound eye and is the distance from the margin of the gena to the margin of the clypeus.

The reference here to "cheek" could be confusing. That term is generally used as a synonym for "gena," meaning the entire side of the head.

For malar space of Andrena, see Andrena Deconstructed Guide.

Bombus: malar space length ~ width.
Andrena: malar space 1/6 as long as wide.

Figure 1. Images of a female Bombus vagans cheek and flagellar segments illustrating the measurement locations for the malar length, malar width, and lengths of flagellar segments 1 and 3. (a) Anatomy of the cheek. (b) Simplified image of the cheek with the mandible removed to show placement of the cheek condyle and cheek acetabulum. (c) Simplified image of the anatomy of the mandible. (d) Flagellar segments 1 and 3 illustrating where to make measurements to record length. Photos a-c by Dennis Johnson.

Details on measurement landmarks for Bombus, in Validating Morphometrics with DNA Barcoding to Reliably Separate Three Cryptic Species of Bombus


mandible

The paired apendages with which bees feed, defend themselves, and manipulate other mouthparts. Female mandibles typically differ in structure, as they are instrumental in collecting and preparing nest materials.

return to top

The number of teeth is often an important character in keys. Anthidium species have from 4 to 8 mandibular teeth.
The dimensions and structure of teeth are important characters in keys for Osmia.
For Osmia, the orientation and sizes of the (lower) condylar and (medial) outer ridges are important traits.

marginal cell

Forewing cell between the costa and submarginal cells.


maxilla

A pair of appendages which are divided in three parts: cardo, which articulates with the head; stipes, which supports a sensory palp; galea and lacinia, which act as fork and spoon to manipulate the food. (All you need is Biology). For more context on mouthparts, see tongue.

return to top


maxillary palp

The upper pair of segmented appendages to the mouthparts, with taste and touch sense. The lower pair, highly modified in long-tongued bees, are the labial palps.

return to top

Alternate views of the maxillary and labial palps of a short-tongued bee.
The length of the palpal segments are diagnostic characters for Andrena.

mesepimeron

Sclerite dorsal to the lower mesepisternum, ventral to the tegula. Image for context: mesosoma.

Mesepimeron - above the mesepisternum.

meso-

A prefix meaning middle. With respect to main body regions, it references the middle of 3 mesosomal segments.  E.g., the mesocoxa are the basal segments of the 2nd (middle) pair of legs.

return to top



mesoscutum

The largest sclerite dorsally on the mesosoma, anterior to the scutellum and posterior to the pronotum.

return to top


mesopleuron

The mid-lateral area of the mesosoma, of which the mesepisternum is the largest (and most diagnostically useful) part. Meso-pleuron might suggest that this is the lateral area of the entire meso-soma. But no, the mesosoma itself has 3 divisions (tagma),  each with sclerites prefixed with pro-, meso-, and meta-. Thus there is a propleuron. mesopleuron, and metapleuron (unhelpfully called the metepisternum). Michener's Bees of the World considers the mesopleuron as a synonym of mesepisternum: the mesothorax is represented by the mesepisternum, sometimes referred to as the mesopleuron. So in practice, references to mesopleuron can be interpreted (unless otherwise specified) as referring to the mesepisternum.


mesepisternum

The sclerite found laterally on the mesosoma, between the coxae and pronotum. See mesopleuron for discussion of terms related to the lateral mesosoma. For many taxa, the traits expressed on the mesepisternum are diagnostically important.


metallic

Descriptive of integument color that is reflective, suggestive of the shininess of metal. Metallic colors are most often a shade of green, blue, or gold, and vary in intensity from "slightly/faintly metallic" to "brilliant." A condition of "slightly" metallic can be hard to discern. In the images near right, an observer ID'd the metallic example only when presented with the dark standard.

return to top

Dark vs slightly metallic tergae.
The slight metallic tint of subgenus Seladonia distinguishes it from other Halictus.

Integument described as "dull metallic," to distinguish from the "brilliant" condition in next photo .
A "brilliantly metallic" Osmia
A metallic species of Andrena
Augorochlora is a common reference for the condition of "brilliantly metallic."
Brilliant-to-iridescent coloration of the orchid bee (Encyclopedia of Life).

mesosoma

The middle region of the body of a bee. This region is sometimes conveniently referred to as the "thorax," but mesosoma is the correct term. Michener in Bees of the World explains: The mesosoma is a compact structure consisting of sclerites of the pro-, meso- and metathoracic segments, which bear the legs and wings, and the first true abdominal segment, termed the propodeum.

One problem with the terms meso- and meta-soma is that one can confuse the similar terms. Note that "s" comes before "t", as the mesosoma comes before the metasoma

return to top

Sclerites of the Andrena mesosoma, dorsal view
Sclerites of Augorochlora mesosoma, lateral view
Map of sclerites for specimen at left.

meta-

A prefix meaning "hind" or "posterior"; used to indicate the posterior (usually 3rd) part of a structure. So of course the third body region is the metasoma. However the mesosoma itself has 3 regions that coincide with each pair of legs. So the metafemur is on the hind leg. The metanotum is a posterior sclerite of the mesosoma. Confused?

return to top


metanotum

The mesosomal sclerite positioned dorsally between the scutellum and propodeum.



metapostnotum

One name for the dorsal portion of the propodeum, aka propodeal triangle, aka propodeal enclosure.


metasoma

The posterior region of the body of a bee. This region is sometimes conveniently referred to as the "abdomen," but metasoma is the correct term in apocritan hymenoptera (ants, bees, and wasps). Each segment of the metasoma includes a dorsal tergite, and a ventral sternite.

return to top

Lateral view of metasoma, adapted from The Bees of the World.
Dorsal view of metasoma.

microsculpture

A search on "microsculpture" and "bee" does not locate a rigorus definition. It does lead you to THE INSECT PORTRAITS OF LEVON BISS, worth seeing. The term microsculpture refers to superficial etching of the integument. This is often referenced in contrast to smooth or more strongly sculptured surface. E.g. T2 surface shining, without tessellation or other microsculpture between the punctures.

return to top

Placeholder image

metepisternum

The lateral sclerite of the mesosoma, positioned between the mesepisternum and propodeum


mouthparts

Bees do far more intricate work with their mouthparts than a typical vertebrate, so there are many parts to unpack. These are treated in separate entries, but the photos here of Laurence Packer provide a particularly elegant overview.

Mouthparts of a short-tongued bee.
Mouthparts of a long-tongued bee.
Long-tongued bee, alternate view.

N

O


occiput

The posterior area of the head within the preoccipital ridge--follow this link for image.

return to top


ocellus

A set of three simple eyes on top of the head, one medial ocellus and two lateral ocelli. Useful in taxonomy as reference points, and as a measure, e.g., Lateral ocellus 2 ocellar diameters from back of head. Useful to bees for one or more hypothesized functions, including flight stabilization, circadian entraining, and polarization sensors (Wikipedia).

return to top

There is no prize for identifying the species. But cool if you can.
Ocelli of a very common eastern species.
The ocellar tangent is a reference for the position of the ocelli relative to the compound eyes.

ochraceous

Color terms in taxonomic works are problematic, as their meanings vary by taxon and taxonomist. One place to start, for ochraceous, is the the Grammatical Dictionary of Botanical Latin which offer  ochre-yellow, yellowish-brown; “ochre color; yellow, imperceptibly changing to brown” (Lindley) “ochre-colored, yellow with a tinge of red” (Jackson); (bryology) “ochre-colored, brownish yellow” (Magill 1990); (in fungi) “ochre-yellowish; ochre-colored.

A reasonable guess is that ochraceous is straw-yellow-ish. There are probably better, more descriptive, everyday words that could be used. E.g., straw, lemon, copper, tawny, honey, ginger, greenish mold-on-white bread.

return to top

Anthophorine bee, with ochracous metasomal hairs and clypeus. BIRL/USGS

omaulus

The lateral (as distinguished from ventral) part of the mesepisternum is divisible into an anterior-facing surface and a lateral-facing surface. The angle between these surfaces varies from gradually rounded through sharply angular to carinate and even lamellate. To avoid expressions like “angle between anterior and lateral surfaces of mesepisternum,” Michener and Griswold (1994a) introduced the term omaulus for this angle. The omaulus, which is not shown in Figure 10-5, is anterior to the episternal groove when the groove is present, and the preomaular area is anterior to the omaulus, i.e., it is the anterior, forward-facing surface of the mesepisternum. Definition and figure from The Bees of the World

return to top


outer ridge

The ridge that runs from the base of the mandible to the apex.

Outer ridge of Osmia mandible.

paraglossa

A paired, lateral lobe of the labium articulated basally with the prementum lateral to the base of the glossa.


paraocular (area)

The lateral region of the face between the eye, and medial frons, supraclypeus, and clypeus.

return to top

Paraocular = green in above.
Paraocular maculation of Hylaeus.

parapsidal line

An incised line at the side of the scutum.

return to top

he parapsidal line is a useful landmark; keys will often refer to pits and sculpturing lateral or medial to the line.
A less distinct parapsidal line, but it is linear, which distinguishes a Hoplitis from Osmia.
Osmia have a punctiform "line" that is nearly invisible.

pedicel

The short, ball-and-socket segment of the antenna, distal to the scape, proximal to the flagellum.

return to top


penicillum

One or more short rows of long curved bristles on the outer side of the apex of the tibia, a structure unique to the Meliponinae. Stingless bees transfer pollen from the middle leg to the hind leg of the same side by pulling the former through the space between the penicillum and the base of the hind basitarsus. Because of the curvature of the penicillum, such movement apparently pushes pollen up into the corbicula (observations of Trigona pallida by the authors). Dual origin of highly social behavior among bees, Winston and Michener1977.

return to top

Red arrows, penicillum of stingless bees. Fig: Michener et al, 1978.
Penicillum of Melipona sp. BIRL/USGS

piceous

As with other technical color terms, interpretations vary. Bugguide: glossy black or glossy brownish-black, i.e., "pitch black" or "pitch brown". Jardine describes this color as "black with a greenish tint; the color of pitch". Gordh (1) says piceous means "pitchy black; black with a reddish tinge".

return to top

Integument as piceous as it is possible to get. BIRL/USGS

pile

Long, soft hair; pilose=hairy; pilosity=hairiness.

return to top

Pilosity of Bombus.
Pilosity of Anthophora urbana.

plumose (hairs)

Branched, often with fine divisions that are closer to "feathery." Plumose hairs (setae) are a feature that generally differentiate bees from wasps. This is usually regarded as an adaptation for collection and retention of pollen, though Michener pointed to the diversity of forms to suggest that: hairs are branched (plumose) in many different ways, some of them not at all suitable for pollen-collecting or pollen-carrying, indicating that the degree or type of plumosity may be under various selective pressures having nothing to do with pollen. Possibly plumosity first arose as one way (an alternative to a great number of hairs) in which forms in a xeric environment could decrease air flow near the integumental surface, and thus reduce water loss (The Bees of the World 2nd Edition., page 60).

There is not (to our knowledge) a common vocabulary for describing types of plumosity, so in many cases one must interpret hairs that are weakly/moderately/highly/consipicuously plumose. There are also alternate terms for "branchy" hairs, including spinulate (tiny spines), pectinate (comb-like), and dendritic.

return to top

Entirely plumose hairs of Halictus.
Plumose hairs of Andrena tibial scopa.

preoccipital ridge (carina)

The ridge that borders a sharply concave area at the back of the head which surrounds the foramen magnum from above, and the sharply concave proboscidial fossa from below.

return to top

Posterior view of  Lasioglossum head.

prementum

The labial sclerite to which the labial palps attach. See tongue for how the prementum relates to the other mouthparts.


proboscidal fossa

The concavity in which the structures of the tongue repose. It is defined laterally by the hypostomal carina.


proclinate

Directed or leaning forward, such as in bristles in particular locations of insects' heads (Wikipedia). The bee-specific references I find apply to hairs of the clypeus and frons of Osmia.

The lower clypeal hairs here are proclinate. Photo from Laurence Packer. Lab www site.
Not proclinate; hairs are vertical or inclined rearward.

pronotal lobe

  A posterior extension of the pronotum, bounded by the mesepistermum below and scutum above.

return to top

Some species (e.g., Ceratina, Anthidium) helpfully display a colored patch on the pronotal lobe.

pronotal ridge

A ridge or crease extending down from the humeral angle. Additional illustration: Andrena Deconstructed Guide.

return to top

Presence of a pronotal ridge is a diagnositc trait for Andrena.In this image, the head is to the right.

pronotum

The collar-like, anteriormost region of the mesosoma. Though valuable in diagnosis, the pronotal traits are often concealed behind the head.

return to top

Anterior view of pronotum of Andrena nuda; pl=pronotal lobe.
Lateral view of pronotum of Andrena nivalis.

pronunciation of latinized vocabulary

The Pronunciation of Biological Latin provides succinct but thorough guidance on how to say latinized terms. In practice, pronunciation may depend on the speaker's primary language, the influence of mentors, and the scientific discipline. You will find deep discussions about the details on the internet, but a couple of quotes are perhaps more empowering: When someone presumes to correct your pronunciation, a knowing smile is an appropriate response. and Pronounce it with confidence! Then everyone else will think they were wrong.

Ah-GAH-pahs-teh-mon. Ah-gah-pahs-TEH-mon. Ah-gah-PAHS-teh-mon.

propodeal triangle, aka: propodeal enclosure, metapostnotum

The upper surface of the propodeum, often delineated by dorsal or lateral ridges (carinae) that form an enclosure. Of the synonymous terms, we prefer "propodeal enclosure" (the enclosure is often not triangular; "metapostnotum" is too far from straightforward English).

return to top

The details of sculpturing are important in diagnosis of Lasioglossum - see examples.
Propodeal triangle of Andrena. More on the Andrena propodeum here.

propodeum

The posteriormost area of the mesosoma (technically the first abdominal segment). See morphology overview for the position of the propdeum in relation to other sclerites. The propodeum is rich with diagnostic features, especially the propodeal enclosure (or triangle). See carinae of the propodeum for some of the important landmarks for Lasioglossum. Details about the Andrena propodeum here.

The propodeum in posterior view.

pruinose

Having a white, powdery covering or bloom. Searching on "pruinose" finds many hits for Peponapis pruinosa, the pruinose squash bee. If we had an image of the pruinose surface of T2, we would add it to this entry.

Placeholder for image.

Pseudopygidial area

An expanded median area extends along the posterior margin on the fifth metasomal tergum of the female and the sixth metasomal tergum of the male of some genera, resembling a pygidial area on the apical tergum (BEM).

return to top

DiscoverLife.
Pseudopygidial area of Halictid (H. ligatus)

pubescence

Covered with short fine hair. The gold (ochraceous) standard might be Xylocopa pubescens--photo at right. Or not;

return to top

iNaturalist observation, photo by Eduardo Millares Ley.

puncture / punctate/punctation

A puncture is a pit. Punctate denotes a field of punctures. Punctation is the particular pattern of puncture distribution. Punctures can be described as large or small; deep or shallow; sparse or dense (crowded). These qualitative descriptors require interpretation which may vary with taxon. Puncture distribution is often (helpfully) quantified, as the ratio of interspace distance (i) to puncture diameter (d) (see photos at right). Descriptions of punctation often also refer to the texture of the interspaces -- polished (glabrous) or roughened (aka microsculptured or tesselate).

return to top

i = interspace; d = pit diameter
i = 1.5 to 2.0d
(Lasioglossum scutum)
Laterally i=0.5d;
Medial i=1.0d
(Lasioglossum scutum)
i <0. d (Paranthidium jugatorium)

pygidium/pygidial plate

The pygidium is the modified dorsal area of metasoma segment 6 (female) or 7 (male). The pygidial plate is the v- or u-shaped area of the pygidium, which functions as a sort of spatula used by females in nest building (the plate of males is sometimes reduced, and likely nonfunctional).

return to top

Drawing adapted from BEM
Among female Andrena, the form of the pygidial plate is a diagnostic clue. The example here has a raised, triangular central area.
Pygidial plate of Eucera.

Q

R


r-vein

The forewing vein that connects to the stigma, between the first submarginal and marginal cells. The length of this vein is a diagnostic character in Andrena keys.

Caption for Image 1
Caption for Image 2

rachis

The main axis of a compound structure ... better explained with reference to the usual usage: the shaft of a bird feather. For bees, rachis usually refers to the tibial spur, upon which there may be teeth.

return to top

Lasioglossum glabiventre: rachis ~ basal tooth, vs L. buccale: rachis wider than basal tooth.

rastellum

A row of spines on the distal end of the tibia used to manipulate pollen.

"At the extremity of the tibia you can also see the "rastellum" that is used collect the pollen from the pollen brush and to transfer it to the pollen press (articulation between the tibia and basitarsus)." (Jacopo Werther; caption and image-Wikimedia commons)"

recurrent veins

There are 2 recurrent veins. Recurrent 1 (= 1st m-cu crossvein) is distal to the medial cell 1. Recurrent 2 (= 2nd m-cu crossvein) is distal to the medial cell 2.

return to top

The S-shaped 2nd recurrent is diagnostic for Colletes.
The position of the junction of the 1st recurrent vein and submarginal cell is a useful character for Andrena. In this case, the junction is at 3/4 of the length of SMC 2.

reticle

You probably need a reticle - an insert to a microscope eyepiece inscribed with a scale. It is often critical to evaluating proportions or ratios of morphological features. E.g., vertex height > 1.5 longer than ocellar diameter, or head height 1.1 times greater than width. In each case, you are likely to argue with yourself about the correct call when differences are small. The reticle provides an objective resolution to the argument.

A typical simple reticle
Vertex height = 2.5 units
Ocellar diameter = 1.0 units ... 2.5/1 = vertex = 2.5 ocellar diameters.

reticulate

Non-bee examples include the color pattern of a giraffe or python, and the detailed venation of leaves. Like with many surface sculpture terms, the default resource is for ants: A glossary of surface sculpturing. The definition for reticulation there: superficially net-like or made up of a network of lines; meshed; netted.

return to top

Dorsal face of propodeum with a rather distinct, median, finely reticulate triangle, somewhat more coarsely reticulate on each side of this (Mitchell - DiscoverLife page).
Reticulate scuplture on head and mesepisternum, Pteromalus (wasp) parasitoid.

rufous/rufescent

tinged with red; reddish-brown or brownish-red, as of rust or oxidised iron (Wikipedia).

There are probably better, more descriptive, everyday words that could be used. E.g., cherry, chestnut, scarlet, blood-red, wine-colored.

Edwyniana near flavicornis. This might be "rufus," but the photographer (I suspect Sam Droege) suggested a stronger term: "tomato-colored."

rugose / rugulose

Having rugae or wrinkles, creases, ridges, or corrugation. Rugulose is the diminutive form.

return to top

Propodeum of Lasioglossum
Mesepisternum of Lasioglossum

S


scabrous / scabriculous

Like with many surface sculpture terms, the default resource is for ants: A glossary of surface sculpturing. The definition for scabrous there: Rough; irregularly and roughly rugose; possessing short, sharp projections or wrinkles. Scabriculous is the dimunitive form: Regularly and finely wrinkled; with fine and regular short, sharp, wrinkles and/or projections. To date we have not seen good examples that clarify how this term is applied to bees, and where it might lie between rugose (coarse) or shagreened (finer).


scape

The first, long segment of the antenna, anchored basally to the antennal socket, articulating distally with the pedicel.

Scape of Lasioglossum.
Nomada generally have impressive scapes. USGS image.

sclerite/sclerotized

A sclerite is an area of the integument or a segment of an appendage which is hard or plate-like and is usually bounded by sutures which may be flexible infoldings of the cuticula (U Cal Riverside). These are formed from the chitinous exoskeleton as individual protein molecules are linked together by quinone compounds. These reactions “solidify” the protein matrix, creating rigid “plates” of exoskeleton known as sclerites.

return to top


scopa

The area on the hind leg or metasomal sternites where a brush of hairs retains the pollen collected by foraging females.

return to top

Svastra obliqua, tibial scopa, with plumose hairs above, minutely barbed hairs below.
Large tibial scopa of Eucerines.
Packed pollen in metasomal scopa of Megachile perihirta.
Femoral scopa of Agapostemon virescens.
Scopae absent: parasitic bees (e.g., Nomada above), and bees that carry pollen internally (Hylaeus spp).

scutellum

The mesosomal sclerite positioned dorsally between the scutum and metanotum.



scutum

The largest sclerite dorsally on the mesosoma, anterior to the scutellum and posterior to the pronotum. More precisely called the mesoscutum.

return to top

Glabrous, punctate scutum (mesoscutum) of Ceratina.

setae

The term is commonly used as a synonym for "hair," which is itself a weak descriptor. Hairs (or setae) have many forms in bees, from simple to branched (plumose), erect to appressed, fine to coarse. In some contexts, "setae" has a more specific meaning, closer to "bristle:" simple, stout, stiff.

The shape and color of setae are important traits for Nomada. Arrows indicate setae in the narrow sense.

shagreened

Googling will not find a clear definition for shagreened, as applied to bees. However the term is used liberally in the literature; the diagnosis for Andrena piperi uses "shagreen" 18 times. Like with many surface sculpture terms, the default resource is for ants: A glossary of surface sculpturing. The definition for shagreened there: covered with a closely set roughness, like the rough-surfaced horse leather termed shagreened; like shark leather. cf., scabriculous. Another take: Discoverlife will use "granular" for shagreened. (The ant glosssary defintion for granulate is in the same ball park: covered with or made up of very small grains or granules.)

Interestingly, the ant glossary lists "Shagreened" as among Obsolete, Vague, and Inaccurate Terms, stating that the term has come to have a range of meanings, from imbricate to rugose, but its actual definition is closest to scabriculous. Counterpoint: "Shagreened" is much more entrenched in the bee literature.

return to top

A generic example - shagreened book binding.
Shagreened tergae of Andrena chlorogaster.

spatulate

Having a wide, blunt end.

Spatulate hairs on the tibia are diagnostic for Osmia nemoris. D. Cappaert
Figure from: A primer of host-plant specialization in bees.  B) Foreleg of Centris neffi (Apidae) (Peru), an oil-collecting specialist from Calceolaria,Scrophulariaceae with modified setae on the basitarsus; (C). Closeup and frontal view of the same species, with the comb onthe left and the few giant spatulate setae on the right, in the middle the stout setae that may serve to open the floral oil-glands,the elaiophores (SEM image by Claus Rasmussen).

spiracle

An external opening to the tracheal respiratory system. Bees have 3 pairs of spiracles in the mesosoma and 7 pairs in the metasoma. These are super-important to the bee, but rarely feature as taxonomic characters.

From key to Anthidini genera (University of Florida): Propodeum with fovea delimited posteriorly by a carina.

spur (tibial spur)

Projection from the tibia where it joins the basitarsus. These are typically paired (exception: honeybees). Diagnostic features include size, shape, and arrangement of teeth.

return to top

a) Regular spur teeth of Halictus farinosus; b) Teeth longer than width of rachis, Lasioglossum glabiventre; c) Curved, twisted spur of Andrena prunorum.

squamose

Spiny, scaly. Squamose hairs are a feature of some cuckoo bees.

Squamose hair band of Serapista pernigra, C. Ritner, Exotic Bee ID.

sternum/sternites

The sclerites of the ventral side of the metasoma. There are usually six clearly visible sternites; segments posterior to these are elaborated as components of the genitalia.

df

stigma

aka prostigma, or pterostigma. A pigmented/ thickened spot on the costal margin of the forewing, usually at the end of the radius (Greek, stigma= mark) (Exotic Bee ID). It is preceded (basally) by the usually narrower prestigma. Together these structures lend stability to the leading edge of the wing.

Length of the stigma, and juncture with r-vein distinguish Diphaglossinae (above) from other taxa (Colletes below). From Key to Bee Families of the World. Photos from Laurence Packer. Lab www site. Lab www site.Lab www site.

sting

The one body part of a bee that could be named by almost anyone, including those who are hazy on the bee/wasp distinction. Among the predatory wasps that gave rise to bees, the sting evolved as an elaboration of the ovipositor, weaponized to deliver venom into insect or spider prey. Among bees, it functions only in defense, and only by females (given its original oviposition function). The sting is not of taxonomic value, to my knowledge.

Stinger of Megachile latimanus.

stipes

The sclerite of the mouthparts joins basally with the cardo, attached distally to the galea, and bearing the maxillary palps. To see its place in relation to other mouthparts, see tongue length.


striate

Like with many surface sculpture terms, the default resource is for ants: A glossary of surface sculpturing. The definition for striate there: Marked with parallel, fine, longitudinal impressed lines or furrows (striae). In most uses of "striate" (for muscles, or rocks), the furrows are superficial. As applied to bees, striate has been applied to deeper sculpturing characterised by raised parallel features (opposite to Harris' definition).

return to top

Striate gena of Agapostemon splendens (see DiscoverLife species page).
Propodeum of Lasioglossum. Mitchell describes this as striate. (see DiscoverLife species page).
Propodeum of Lasioglossum. Gibbs describes this as: anastomosing rugae not reaching apical margin (see DiscoverLife species page).
Propodeum of Lasioglossum. Gibbs describes this as carinulate (see DiscoverLife species page).

strigilis

An organ on the first tarsal joint of a bee's foreleg, used to curry or clean the antennae. Additional description from NATURAL HISTORY AND ECONOMY OF THE BEES:  Indigenous to the British Isles. W. E. SHUCKARD, 1866....on the anterior tibiæ of all the bees, there is, within, a small velum, or sail, as it has been called; this is a small angular appendage affixed within the spur by its base. At the base of the palmæ of the same legs, and opposite the play of this velum, there is a deep sinus, or curved incision, the strigilis, called thus or the curry-comb, from the pecten, or comb of short stiff hair which fringes its edge. Upon this aperture the velum can act at the will of the insect, and combined they form a circular orifice. The object of this apparatus is to keep the antennæ clean, for the insect, when it wishes to cleanse one or the other of them, lays it within this sinus of the palma, and then, pressing the velum of the spur upon it, removes, by the combined action of the comb and the velum, all excrescences or soilure from it, and this process it repeats until satisfied with the cleanliness of the organ.

return to top

Components include the velum, which opposes the circular opening, and the spine.
Another Osmia species, with an elongate pointed spine.
Drawing from the British Bee Journal, 1878.

stylops

A genus of obligately endoparasitic insects in the family Stylopidae. Stylops larvae emerge from their host bee while the host gathers pollen from flowers. The larvae then attach to other bees in order to be carried back to the nest. At the nest, the Stylops larvae enter the bodies of bee larvae and develop along with their host. Adult males leave their hosts to mate with females, who remain inside their host and hatch their eggs there (Wikipedia). Fuller explanation: Stylopized, emasculated and zombified: the risks of visiting a flower

return to top

Stylopid adult on Andrena, iNaturalist observation. Tina LaBonte
Fig. 1. (A) Two male Stylops ater in copulation attempt with an extruded female (not visible in photograph) in a female Andrena vaga [Theaterpark (Braunschweig), 25.02.2021; photograph credit: Robin Schmidt]. (B) Egg of A. vaga with primary larvae of S. ater on pollen provision in brood cell. (C) Dissected abdomen of female A. vaga parasitized by female S. ater. (D) Dissected abdomen of female A. vaga formerly parasitized by male S. ater (ce, cephalothorax; il, ileum; mp, male puparium; re, rectum; sa, Stylops abdomen).Anatomical, phenological and genetic aspects of the host–parasite relationship between Andrena vaga (Hymenoptera) and Stylops ater (Strepsiptera)

subantennal suture

A vertical line--suture--that connects the antennal socket to the horizontal epistomal suture that defines the top of the clypeus.

return to top

Bees generally have a single subantennal suture. In the Andrenidae, there are two.
The two sutures of Panurginus (Andrenidae). This trait is diagnostic of the family, but is often difficult to discern in the hairier Andrena.

sub -apical -equal etc

A prefix that means "not quite." A subapical manidbular tooth is short of the apex. Lateral ocelli equal each other in size, but might be subequal (not quite equal) to the median ocellus. Another meaning is below or underneath. The submarginal cells are  beneath the marginal cell.


subgenal coronet

The presence of a ring of hairs on the underside of [the Andrena] face is called the "subgenal coronet" (Wikipedia). We do not find a more rigorous definition or example images of the subgenal coronet. The feature is judged to be the most solid character which unequivocally defines the entire genus Andrena ... and does not occur else where among bees, except in Cubiandrena (Phylogeny of the bee genus Andrena FABRICIUS based on morphology).


submarginal cells

Cells of the forewing, below the marginal cell. Number (two or three), size, position, and connections are important diagnostic clues.

return to top

Bees of the family Apidae have 3 SMCs.
A megachilid, with the typical 2 SMCs.

sulcus

A fold, groove, or boundary; a suture which is deeply grooved or forms a distinct furrow.


supraclypeus (supraclypeal area)

The part of the face that is bounded below by the top of the clypeus, laterally by the subantennal sutures, and above by the antennal bases. The supraclypeal area is the preferred  term, as it is not entirely bordered by sulci.

return to top

Density of pits, and surface texture of the supraclypeus are useful traits for Lasioglossum.
For two similar Halictus, the shape of the supraclypeus differentiates species.

suture

The incised border between sclerites of the exoskeleton.


syrphid

The diptera family also known as hoverflies or flowerflies. Worthy of consideration as pollinators (second only to bees), and as beautiful and complex animals in their own right. There is a very accessible and authoritative 339 page  Key to the Genera of Nearctic Syrphidae.

Cheilosia grossa. You will need a different glossary for syrphid terms.
Syritta pipiens, the thick-legged hoverfly.

T


tarsus

The 5 leg segments distal to the tibia, comprised of an enlarged basitarsus, 3 mediotarsi, and the terminal distitarsus.


taxon

Organisms are grouped into taxa (singular: taxon) and these groups are given a taxonomic rank; groups of a given rank can be aggregated to form a more inclusive group of higher rank, thus creating a taxonomic hierarchy (Wikipedia). One way to use the term is in reference to a set of specimens with different known taxonomic ranks. "Three taxa were observed" might include a honeybee (species), a bumblebee (genus), and a syrphid (family).


tegula

A small, scale-like sclerite covering the base of the fore wing, basal to the humeral plate.

The shape of the tegula is key to differentiating Eucera and Melissodes.

tergum / tergite

The dorsal portion of an arthropod segment other than the head. For bees, a tergum (plural: tergae) typically refers only to the metasoma. Tergae are numbered from the anteriormost (T1) to the posteriormost (visible) segment (T6 for females, T7 for males). "Tergite," properly referring to a portion of the segment is also used as a synonym for tergum.


tesselate

Impressed sculpturing with a pattern of repeated shapes that fit together closely without gaps or overlapping; resembling mosaic or tiles.

return to top

Tesselate scutum of Lasioglossum.
Scutum of Andrena.

thorax

A term for the middle section of a standard 3-part insect. However, what appears as the "thorax" for bees is properly called the mesosoma.


tibia

The leg segment distal to the femur, articulating distally wiith the basitarsus.

return to top

Foreleg of Halictus
Foreleg of Halictus (tarsi missingf)
The very interesting tibia (largest segment) of an orchid bee. Photo by Alejandro Santillana, "Insects Unlocked."

tomentum

Pubescence consisting of soft, entangled hairs pressed close to the surface of the integument (Wikipedia).

return to top

Tomentum on the face below the antenna, obscuring underlying integument.
Tomentum basolaterally on tergites. Also visible are the erect plumose hairs on T1, and simple dark setae on T2,
Tomentose, appressed hairs on posterior tergae of Lasioglossum. On the anterior face of T1, the hairs are appressed, but not tomentose.

tongue - general scheme

There are two general, somewhat fuzzy, paraphyletic groups: short- and long-tongued bees. Fuzzy because the tongue (glossa) length may be long in the short-tongued species, and vice-versa. The main structures are indicated in the figures at right. The coloring book versions are useful but unsatisfying; click on the video for a better sense of how it all works.

Bee mouthparts are comprised of many distinct elements, in configurations that vary by taxon, reflecting the many solutions to the problem of obtaining and collecting pollen and nectar. A detailed treatment of mouthpart anatomy and vocabulary are beyond the scope of this glossary; see Bees of the World (pp 83-88) for more.

return to top

Graphic from Paleontological Research Institution. Worth opening in a new tab.
Spread mouthparts of a long-tongued bee.
Above: short-tongued bee, Lasioglossum. Below: long-tongued bee, Eucera.
Spread mouthparts of a short-tongued bee.
Melissodes, a long tongued bee.

triungulin

The mobile first instar larva of an insect that undergoes hypermetamorphosis. The term triungulin is technically applied only to the three-clawed (hence the name) planidia in the Meloidae--Blister Beetle . Sometimes the term is often used in a broader sense, meaning any similar mobile first-instar larva, i.e., planidium. Definition from Bugguide.

return to top

On this Andrena metasoma, two life stages of   thrips larvae called triungulins enter their host and develop inside it. Females remain inside the host; when ready to breed, they will push their head and brood canal opening, which is located just behind their head, out between the host insect's sclerites (Wikipedia: Stylopidae)
Triungulins on Andrena USGS BIML
Meloid on Nomada.

trochanter

The leg segment distal to the coxa and proximal to the femur.

The rounded "corner" of the trochanter (below in pic) is a character for Ceratina males.
An Andrena feature: a trochanteral flocculus.


truncate

Having a blunt end, as though cut off at the tip.

Two similar Andrenid genera differ in the shape of the marginal cell: tapered in Andrena, truncate in Panurginus.

tubercle

A small abrupt elevation, like a knob or pimple.

The prominence between the antennal bases of Xylocopa virginica: described as a carinate tubercle.

U

V


vannal lobe

The posterior, area of the hind wing, distal to the jugal lobe. The relative size of the vannal and jugal lobes features in keys. Issue: hind wing lobes are often folded and difficult to assess.

return to top


velum

The structure opposing the comb of the strigilis (antenna cleaner) on the foreleg.

Among Osmia, the velum bears an apical spine - blunt in this specimen.
Another Osmia, with a distincly acute apical spine.

vertebrate

An animal phylum that includes fish, mammals, and dinosaurs. Lacking an exosekeleton, the external morphology of vertebrates is monotonous, with few useful diagnostic traits. Compared to arthropods, and according to an entomologist, vertebrates exhibit low taxonomic and functional diversity.

Fish are distinguished by a lack of legs, and an imbricate integument.
Other vertebrates have 4 legs/wings. X-ray view of an amphibian.


vertex

The area between the lateral ocelli and the back of the head. Height (ocellus-->posterior edge) and shape/curvature are commonly cited traits.

return to top

Frontal view; dotted line is the anterior margin of the vertex.
The length of the vertex is often described as a multiple of "ocellar diameters,", i.e., median width of the center ocellus. In the image above, the vertex height (or length) is ~1 ocd.
In the image above, the vertex height (or length) is >2 ocd.

violaceous

A color term that is self-explanatory. Of course you could use purple, plum, eggplant, or to be more precise, Crayola Vivid Violet.

Eufriesea purpurata, an orchid bee, is a good example of violaceous.
Brilliantly metallic Osmia with violaceous reflections.

volsella

From Bees of the World: "Most easily identified by the heavily sclerotized dark teeth on the opposable surfaces of the digitus and cuspis ... in bees the volsellae are reduced (often wanting) and the digitus becomes fused to the body of the volsella and thus immovable." This definition exemplifies the issue with genitalia, and the reason why the structures are not (yet) covered in this glossary--see justification in entry for genitalia.

However: I had a reason to examine the volsella of a Bombus, because the shape is a key diagnostic--see photo.

The volsellae are the orange-fringed structures, which for this Bombus species are "narrow and finger shaped."

W


wings

Every vein and cell of the wings of bees has a term (or two). Most of the diagnostically useful characters are on the forewing; these are listed in separate glossary entries. Hindwings appear in keys that ask for the relative lengths of the jugal and vannal lobes.

return to top

Principle landmarks of the forewing of Nomada.

Forewings of several taxa

Feature of Megachilidae: two submarginal cells.
Feature of Halictidae (lower right images): arched basal vein.
Andrenidae and Colletidae: taxa with either 2 or 3 submarginal cells.

X


Placeholder for the letter X

Until such time as I encounter an entry for "X," I give this space to Xeromelecta californica (male). Photo from Laurence Packer. Lab www site.


Z

Placeholder for the letter Z

Until such time as I encounter an entry for "Z," I give this space to Zacosmia maculata (female). Photo from Laurence Packer. Lab www site.

The Bees of the World 2nd Edition.Charles Duncan Michener, 2007. "A definitive reference by an acclaimed expert accounts for 1200 genera/subgenera and 16,000 species of bees in the world."

Hymenoptera of the World: An Identification Guide to Families. Goulet and Huber, 1993.

The Bee Genera of North and Central America. Michener, McGinley, Danforth. 1994.

USGS Native Bee Inventory and Monitoring Lab. Manager of DiscoverLife guides, and source for hi-resolution catalog of over 4500 photographs of bees, other insects, and plants.

Morphology and External Morphology, Oregon State University Agri Expt Stn, 1969.

Pollen Manipulation and Related Activities and Structures in Bees of the Family Apidae.Michener et al 1978. "A definitive reference by an acclaimed expert accounts for 1200 genera/subgenera and 16,000 species of bees in the world."

Studies of Halictinae (Apoidea: Halictidae), I: Revision of New World Lasioglossum Curtis, RJ McGinley, 1986
Overlay Image
TRIGGERS 0 = table entry with no image. 1 = single image 2 = 2 images 3 = 3 images hr = heavy rule Dec 29: My new defaults no longer include a view button. Any image magnifies on a click. If I want a view button, I use this:
Caption for Image
REGULAR EXPRESSION TO KILL BULLETS (use Brackets) FIND:

See also:<\/p>[\s\S]*?<\/ul>
